C2960X Switches 48 Port Gigabit Switch LAN Lite WS-C2960X-48TD-L

Name: C2960X Switches 48 Port Gigabit Switch LAN Lite WSC2960X48TDL
Brand: WS-C2960X-48TD-L
Price: 750.00 USD

China C2960X Switches 48 Port Gigabit Switch LAN Lite WS-C2960X-48TD-L factory

Brand Name : WS-C2960X-48TD-L

Model Number : WS-C2960X-48TD-L

Place of Origin : BEI

Packaging Details : New original packaging

Supply Ability : 50 Piece/Pieces per Day

MOQ : 2 pieces

Price : $750.00/pieces 2-199 pieces

Payment Terms : L/C, D/A, D/P, T/T, Western Union

Delivery Time : 3-5days

Private Mold : NO

Products Status : Stock

Ports : ≥ 48

Transmission Rate : 10/100/1000Mbps

Function : LACP, POE, QoS, SNMP, stackable, VLAN Support

Communication Mode : Full-Duplex & Half-Duplex

Switch Capacity : 216g

Product Name : WS-C2960X-48TD-L

Condition : NIB Original

Warranty : 1 Year

Dimensions (H x W x D) : 44.5 cm x 27.9 cm x 4.5 cm

Package Weight : 12kg

Lead time : 2-3 Working Days

Series : 2960x

Contact Now

Product Description

WS-C2960X-48TD-L Overview

Cisco Catalyst 2960X-48TD-L LAN Base stackable Layer 2 switch provides enterprise-class access for campus and branch applications. It is comprised of 48 Ethernet 10/100/1000 ports and 2 x 10G SFP+ uplink interfaces.

Quick Specs

Figure 1 shows the front view of the Cisco 2960X-48TD-L switch.

C2960X Switches 48 Port Gigabit Switch LAN Lite WS-C2960X-48TD-L

Table 1 shows the Quick Spec of the Cisco 2960X-48TD-L switch.

Product Code	WS-C2960X-48TD-L
Enclosure Type	Rack-mountable - 1U
Feature Set	LAN Base
Uplink Interfaces	2 x 10G SFP+
Ports	48 x Ethernet 10/100/1000 Gigabit ports
Maximum stacking number	8
Stack bandwidth	80G
Forwarding Bandwidth	108Gbps
Switching Bandwidth	216Gbps
RAM	512MB
Flash Memory	128MB
Dimensions	44.5 cm x 27.9 cm x 4.5 cm
Package Weight	9.19 Kg

Product Details

Figure 2 shows the front panel of the Cisco Catalyst 2960X-48TD-L switch.

Note:

①	Ethernet management port	⑥	SFP module port
②	Mode button	⑦	48 x 10/100/1000 ports
③	Switch LEDs	⑧	CONSOLE LED
④	USB mini-Type B (console) port	⑨	MGMT LED
⑤	USB Type A ports	⑩	RJ-45 console port

·The Switch LEDs include SYST, STAT, SPEED, RPS, MAST, and STACK LEDs.

Figure 3 shows the back panel of the Cisco Catalyst 2960X-48TD-L switch.

Note:

①	FlexStack-Plus module slot and cover	③	RPS Connector
②	Fan Exhaust	④	AC power connector

Figure 4 shows the stackable capacity.

This C2960X switch delivers stackable capacity that supports up to 8 switches stacking with same 2960-X LAN base series. It also can stack up to 4 switches stacking when mixed with 2960-S LAN base series switches.

C2960X Switches 48 Port Gigabit Switch LAN Lite WS-C2960X-48TD-L

The Accessories

Table 2 shows some accessories of the WS-C2960X-48TD-L.

Models	Description
C2960X-STACK	Catalyst 2960-X FlexStack Plus Stacking Module
CAB-STK-E-0.5M	Cisco FlexStack Stacking Cables
GLC-LH-SMD	Cisco GLC-LH-SMD 1000BASE-LX/LH SFP transceiver module, MMF/SMF, 1310nm, DOM
GLC-SX-M MD	1000BASE-SX SFP transceiver module, MMF, 850nm, DOM
CAB-CONSOLE-RJ45	Console Cable 6ft with RJ45 and DB9F
CAB-CONSOLE-USB	Console Cable 6 ft with USB Type A and mini-B
